| 型號 | 流量Q | 揚程（M） | 效率（％） | 轉速(r/min) |
電機功率 （KW） |
必需汽蝕 余量 （NPSH）r |
重量 | |
| （m3/h) | （L/S） | |||||||
| 40-100 | 3.2 | 0.89 | 3 | 48 | 1400 | 0.12 | 2.5 | 17 |
| 40-125 | 3.2 | 0.89 | 5 | 40 | 1400 | 0.18 | 2.5 | 19 |
| 40-125A | 2.8 | 0.78 | 4 | 39 | 1400 | 0.12 | 2.5 | 19 |
| 40-160 | 3.2 | 0.89 | 8 | 36 | 1400 | 0.25 | 2.5 | 24 |
| 40-160A | 2.8 | 0.78 | 6.4 | 35 | 1400 | 0.18 | 2.5 | 22 |
| 40-200 | 3.2 | 0.89 | 12.5 | 31 | 1450 | 0.55 | 2.5 | 38 |
| 40-200A | 2.8 | 0.78 | 10 | 30 | 1400 | 0.37 | 2.5 | 30 |
| 40-250 | 3.2 | 0.89 | 20 | 25 | 1450 | 1.1 | 2.5 | 52 |
| 40-250A | 2.8 | 0.78 | 16 | 25 | 1450 | 0.75 | 2.5 | 47 |
| 40-250B | 2.3 | 0.64 | 13 | 24 | 1450 | 0.55 | 2.5 | 46 |
| 40-100(I) | 6.3 | 1.75 | 3 | 54 | 1400 | 0.12 | 2.5 | 17 |
| 40-125(I) | 6.3 | 1.75 | 5.0 | 54 | 1400 | 0.25 | 2.5 | 29 |
| 40-125(I)A | 5.6 | 1.56 | 4.0 | 52 | 1400 | 0.18 | 2.5 | 24 |
| 40-160(I) | 6.3 | 1.75 | 8.0 | 47 | 1450 | 0.55 | 2.5 | 43 |
| 40-160(I)A | 5.1 | 1.42 | 5.3 | 45 | 1400 | 0.25 | 2.5 | 30 |
| 40-200(I) | 6.3 | 1.75 | 12.5 | 40 | 1450 | 0.75 | 2.5 | 45 |
| 40-200(I)A | 5.5 | 1.53 | 9.5 | 39 | 1450 | 0.55 | 2.5 | 44 |
| 40-250(I) | 6.3 | 1.75 | 20 | 32 | 1450 | 1.5 | 2.5 | 54 |
| 40-250(I)A | 5.6 | 1.56 | 16 | 32 | 1450 | 1.1 | 2.5 | 49 |
| 40-250(I)B | 5.1 | 1.42 | 13 | 30 | 1450 | 0.75 | 2.5 | 42 |
| 50-100 | 6.3 | 1.75 | 3 | 54 | 1400 | 0.12 | 2.5 | 19 |
| 50-125 | 6.3 | 1.75 | 5.0 | 54 | 1400 | 0.25 | 2.5 | 25 |
| 50-125A | 5.6 | 1.56 | 4.0 | 52 | 1400 | 0.18 | 2.5 | 19 |
| 50-160 | 6.3 | 1.75 | 8.0 | 47 | 1450 | 0.55 | 2.5 | 42 |
| 50-160A | 5.1 | 1.42 | 5.3 | 45 | 1400 | 0.25 | 2.5 | 37 |
| 50-200 | 6.3 | 1.75 | 12.5 | 40 | 1450 | 0.75 | 2.5 | 48 |
| 50-200A | 5.5 | 1.53 | 9.5 | 39 | 1450 | 0.55 | 2.5 | 46 |
| 50-250 | 6.3 | 1.75 | 20 | 32 | 1450 | 1.5 | 2.5 | 58 |
| 50-250B | 5.1 | 1.42 | 13 | 30 | 1450 | 0.75 | 2.5 | 49 |
| 50-100(I) | 12.5 | 3.47 | 3 | 63 | 1400 | 0.25 | 2.5 | 23 |
| 50-125(I) | 12.5 | 3.47 | 5.0 | 63 | 1400 | 0.37 | 2.5 | 34 |
| 50-125(I)A | 11.0 | 3.06 | 3.8 | 60 | 1400 | 0.25 | 2.5 | 33 |
| 50-160(I) | 12.5 | 3.47 | 8 | 59 | 1450 | 0.55 | 2.8 | 46 |
